PG存储astore解析二

结合代码流程解析插入、删除流程。

插入流程

调用链

main
 PostmasterMain
  ServerLoop
   BackendStartup
    BackendRun
     PostgresMain
      exec_simple_query # 词法解析/语法解析/优化器
       PortalRun
        PortalRunMulti
         ProcessQuery
          standard_ExecutorRun
           ExecutePlan
            ExecProcNode
             ExecModifyTable
              ExecInsert
               table_tuple_insert # 通过 default_table_access_method选择执行函数
                heapam_tuple_insert # 选择了 heap access method.
                 heap_insert # 插入元组

insert into t1 values(4,4); 其中exec_simple_query的逻辑如下：

exec_simple_query
--> pg_parse_query   //语法解析
    --> raw_parser
        --> base_yyparse
--> pg_analyze_and_rewrite //语义分析
    --> parse_analyze
        --> transformStmt
            --> transformInsertStmt

--> pg_plan_queries    //查询优化，生成执行计划
    --> pg_plan_query
        --> standard_planner
            --> subquery_planner
                --> grouping_planner
                    --> query_planner
                        --> build_simple_rel
                        --> make_one_rel
                    --> create_modifytable_path
            --> create_plan
--> PortalStart
--> PortalRun
    --> ProcessQuery
        --> ExecutorStart
            --> InitPlan
                --> ExecInitModifyTable
        --> ExecutorRun
            --> ExecutePlan
                --> ExecModifyTable
                    --> planSlot = ExecProcNode(subplanstate); // 执行子执行计划Result，获取要插入的tuple值， 对应values(4,4)
                    --> ExecInitInsertProjection
                    --> ExecGetInsertNewTuple
                    --> ExecInsert  // -----执行插入------
                        --> table_tuple_insert
        --> ExecutorEnd
--> PortalDrop

ExecInsert

heap_insert主要是四个步骤：

1. 从values形成要插入的tuple heap_prepare_insert
2. 从Buffer中获取一个页 RelationGetBufferForTuple
3. 向缓冲页插入tuple，标记脏页 RelationPutHeapTuple
4. 写WAL日志

ExecInsert  // 执行插入
--> table_tuple_insert
    --> heap_insert
        /********  Buffer中向Page插入一条tuple ***********/
        --> GetCurrentTransactionId()
        --> heap_prepare_insert  // 1.准备tuple
        --> RelationGetBufferForTuple // 2. Buffer中获取足够插入tuple大小的页，
            --> GetPageWithFreeSpace
                --> fsm_search  // 结合fsm，查找含有足够空闲size的页
        --> CheckForSerializableConflictIn
        --> RelationPutHeapTuple // 3. 向页中插入tuple
            --> BufferGetPage(buffer);
            --> PageAddItemExtended
        --> MarkBufferDirty
        /******** 4.写WAL日志 ***********/
        --> XLogBeginInsert
        --> XLogRegisterData
        --> XLogRegisterBuffer
        --> XLogRegisterBufData
        --> XLogSetRecordFlags
        --> XLogInsert
            --> XLogRecordAssemble  // 由前面的信息生成日志记录
            --> XLogInsertRecord    // 插入WAL日志中
                --> CopyXLogRecordToWAL(rechdr->xl_tot_len, isLogSwitch, rdata,StartPos, EndPos);
                    -->  GetXLogBuffer(CurrPos)
                --> XLogFlush(EndPos)
                    --> XLogWrite // 写入WAL日志文件

        --> PageSetLSN(page, recptr);

heap_prepare_insert的主要作用是设置Tuple元组头部信息，包括oid、xmin、xmax、cid等等，如果Tuple可以Toast则执行toast_insert_or_update。

RelationGetBufferForTuple：

1. 计算元组需要预留的大小，加上元组大小不能超过元组最大大小
2. 要插入的页尽可能是刚插入过的页，没有的话就从fsm上获取一页，如果没有fsm信息或fsm不够大，就获取关系表的最后一页
3. 为获取的页加锁
4. 检查是否pin和lock成功了这些页，并保证成功（pin操作是在vm里）
5. 检查空间是否足够，如果空间够了，就返回这个buffer，如果空间不够，就重新获取
6. 如果fsm中都不够用，就扩展表
7. 对于扩展后的表，要将页初始化，再返回这个buffer

RelationPutHeapTuple：

1. 根据 buffer获取Page
2. 执行 pageAddItemExtend
3. 更新 元组指针 itemid 的 ctid

PageAddItemExtended

主要是四步：

1. 如果指定offsetNumber，则在指定偏移处覆盖数据，返回
2. 否则找到空闲的Linp（或slot）
3. 如果没有空闲的Linp则在其后找一个位置
4. 设置item指向upper、拷贝数据到upper、更新lower和upper

OffsetNumber
PageAddItemExtended(Page page,
					Item item,
					Size size,
					OffsetNumber offsetNumber,
					int flags)
{
	PageHeader	phdr = (PageHeader) page;
	Size		alignedSize;
	int			lower;
	int			upper;
	ItemId		itemId;
	OffsetNumber limit;
	bool		needshuffle = false;

	/*
	 * Be wary about corrupted page pointers
	 */
	if (phdr->pd_lower < SizeOfPageHeaderData ||
		phdr->pd_lower > phdr->pd_upper ||
		phdr->pd_upper > phdr->pd_special ||
		phdr->pd_special > BLCKSZ)
		ereport(PANIC,
				(errcode(ERRCODE_DATA_CORRUPTED),
				 errmsg("corrupted page pointers: lower = %u, upper = %u, special = %u",
						phdr->pd_lower, phdr->pd_upper, phdr->pd_special)));

	/*
	 * Select offsetNumber to place the new item at
	 */
	limit = OffsetNumberNext(PageGetMaxOffsetNumber(page));

	/* was offsetNumber passed in? */
	if (OffsetNumberIsValid(offsetNumber))
	{
		/* yes, check it */
		if ((flags & PAI_OVERWRITE) != 0)
		{
			if (offsetNumber < limit)
			{
				itemId = PageGetItemId(phdr, offsetNumber);
				if (ItemIdIsUsed(itemId) || ItemIdHasStorage(itemId))
				{
					elog(WARNING, "will not overwrite a used ItemId");
					return InvalidOffsetNumber;
				}
			}
		}
		else
		{
			if (offsetNumber < limit)
				needshuffle = true; /* need to move existing linp's */
		}
	}
	else
	{
		/* offsetNumber was not passed in, so find a free slot */
		/* if no free slot, we'll put it at limit (1st open slot) */
		if (PageHasFreeLinePointers(phdr))
		{
			/*
			 * Look for "recyclable" (unused) ItemId.  We check for no storage
			 * as well, just to be paranoid --- unused items should never have
			 * storage.
			 */
			for (offsetNumber = 1; offsetNumber < limit; offsetNumber++)
			{
				itemId = PageGetItemId(phdr, offsetNumber);
				if (!ItemIdIsUsed(itemId) && !ItemIdHasStorage(itemId))
					break;
			}
			if (offsetNumber >= limit)
			{
				/* the hint is wrong, so reset it */
				PageClearHasFreeLinePointers(phdr);
			}
		}
		else
		{
			/* don't bother searching if hint says there's no free slot */
			offsetNumber = limit;
		}
	}

	/* Reject placing items beyond the first unused line pointer */
	if (offsetNumber > limit)
	{
		elog(WARNING, "specified item offset is too large");
		return InvalidOffsetNumber;
	}

	/* Reject placing items beyond heap boundary, if heap */
	if ((flags & PAI_IS_HEAP) != 0 && offsetNumber > MaxHeapTuplesPerPage)
	{
		elog(WARNING, "can't put more than MaxHeapTuplesPerPage items in a heap page");
		return InvalidOffsetNumber;
	}

	/*
	 * Compute new lower and upper pointers for page, see if it'll fit.
	 *
	 * Note: do arithmetic as signed ints, to avoid mistakes if, say,
	 * alignedSize > pd_upper.
	 */
	if (offsetNumber == limit || needshuffle)
		lower = phdr->pd_lower + sizeof(ItemIdData);
	else
		lower = phdr->pd_lower;

	alignedSize = MAXALIGN(size);

	upper = (int) phdr->pd_upper - (int) alignedSize;

	if (lower > upper)
		return InvalidOffsetNumber;

	/*
	 * OK to insert the item.  First, shuffle the existing pointers if needed.
	 */
	itemId = PageGetItemId(phdr, offsetNumber);

	if (needshuffle)
		memmove(itemId + 1, itemId,
				(limit - offsetNumber) * sizeof(ItemIdData));

	/* set the item pointer */
	ItemIdSetNormal(itemId, upper, size);

	/*
	 * Items normally contain no uninitialized bytes.  Core bufpage consumers
	 * conform, but this is not a necessary coding rule; a new index AM could
	 * opt to depart from it.  However, data type input functions and other
	 * C-language functions that synthesize datums should initialize all
	 * bytes; datumIsEqual() relies on this.  Testing here, along with the
	 * similar check in printtup(), helps to catch such mistakes.
	 *
	 * Values of the "name" type retrieved via index-only scans may contain
	 * uninitialized bytes; see comment in btrescan().  Valgrind will report
	 * this as an error, but it is safe to ignore.
	 */
	VALGRIND_CHECK_MEM_IS_DEFINED(item, size);

	/* copy the item's data onto the page */
	memcpy((char *) page + upper, item, size);

	/* adjust page header */
	phdr->pd_lower = (LocationIndex) lower;
	phdr->pd_upper = (LocationIndex) upper;

	return offsetNumber;
}

删除流程

这里贴上博客的内容，写得很好，不重新造轮子。

heap_delete
	buffer = ReadBuffer(relation, block);
	// 并发更新判断元组的状态
  result = HeapTupleSatisfiesUpdate(&tp, cid, buffer, allow_delete_self);

/*
 *	heap_delete - delete a tuple
 *
 * See table_tuple_delete() for an explanation of the parameters, except that
 * this routine directly takes a tuple rather than a slot.
 *
 * In the failure cases, the routine fills *tmfd with the tuple's t_ctid,
 * t_xmax (resolving a possible MultiXact, if necessary), and t_cmax (the last
 * only for TM_SelfModified, since we cannot obtain cmax from a combo CID
 * generated by another transaction).
 */
TM_Result heap_delete(Relation relation, ItemPointer tid,
			CommandId cid, Snapshot crosscheck, bool wait,
			TM_FailureData *tmfd, bool changingPart)
{
	TM_Result	result;
	TransactionId xid = GetCurrentTransactionId();			// 写操作事务均需要获取事务号
	ItemId		lp;
	HeapTupleData tp;
	Page		page;
	BlockNumber block;
	Buffer		buffer;
	Buffer		vmbuffer = InvalidBuffer;
	TransactionId new_xmax;
	uint16		new_infomask,
				new_infomask2;
	bool		have_tuple_lock = false;
	bool		iscombo;
	bool		all_visible_cleared = false;
	HeapTuple	old_key_tuple = NULL;	/* replica identity of the tuple */
	bool		old_key_copied = false;

	Assert(ItemPointerIsValid(tid));                        // 删除元组的 tid上层函数传入

	/*
	 * Forbid this during a parallel operation, lest it allocate a combo CID.
	 * Other workers might need that combo CID for visibility checks, and we
	 * have no provision for broadcasting it to them.
	 */
	 // 删除一条元组禁止开并行模式
	if (IsInParallelMode())
		ereport(ERROR,
				(errcode(ERRCODE_INVALID_TRANSACTION_STATE),
				 errmsg("cannot delete tuples during a parallel operation")));

	// 根据元组的 tid确定块号，并根据块号和 relation 描述符将数据块加载时共享缓冲区中buffer，获取页地址
	block = ItemPointerGetBlockNumber(tid);
	buffer = ReadBuffer(relation, block);
	page = BufferGetPage(buffer);

	/*
	 * Before locking the buffer, pin the visibility map page if it appears to
	 * be necessary.  Since we haven't got the lock yet, someone else might be
	 * in the middle of changing this, so we'll need to recheck after we have
	 * the lock.
	 */
	 // 由于删除元组，势必会修改VM对应标识位，如果数据页含有 allvisible标记，则需要将数据页对应的VM页加载至
	 // vmbuffer(pin住)
	if (PageIsAllVisible(page))
		visibilitymap_pin(relation, block, &vmbuffer);

	// 对 buffer施加排他锁
	LockBuffer(buffer, BUFFER_LOCK_EXCLUSIVE);

	/*
	 * If we didn't pin the visibility map page and the page has become all
	 * visible while we were busy locking the buffer, we'll have to unlock and
	 * re-lock, to avoid holding the buffer lock across an I/O.  That's a bit
	 * unfortunate, but hopefully shouldn't happen often.
	 */
	 // 在获取上述缓冲块排他锁期间，可能有其他进程将对应的VM 数据页标记信息更新为 allvisible,那么此时
	 // 需要释放buffer 排他锁，pin住 vmbuffer,后在此获取buffer排他锁。，其目的是为了防止在持有buffer
	 // 排他锁行执行 io (加载vm page 至 vmbuffer)
	if (vmbuffer == InvalidBuffer && PageIsAllVisible(page))
	{
		LockBuffer(buffer, BUFFER_LOCK_UNLOCK);
		visibilitymap_pin(relation, block, &vmbuffer);
		LockBuffer(buffer, BUFFER_LOCK_EXCLUSIVE);
	}

	// 获取偏移量为tid的元组相关信息
	lp = PageGetItemId(page, ItemPointerGetOffsetNumber(tid));
	Assert(ItemIdIsNormal(lp));

	tp.t_tableOid = RelationGetRelid(relation);
	tp.t_data = (HeapTupleHeader) PageGetItem(page, lp);
	tp.t_len = ItemIdGetLength(lp);
	tp.t_self = *tid;

l1:
	// 可见性判断：根据其结果判断元组是否满足被更新/删除
	result = HeapTupleSatisfiesUpdate(&tp, cid, buffer);

	// 元组不可见，报错
	if (result == TM_Invisible)
	{
		UnlockReleaseBuffer(buffer);
		ereport(ERROR,
				(errcode(ERRCODE_OBJECT_NOT_IN_PREREQUISITE_STATE),
				 errmsg("attempted to delete invisible tuple")));
	}
	// 该元组正在被更新，且等待
	else if (result == TM_BeingModified && wait)
	{
		TransactionId xwait;
		uint16		infomask;

		/* must copy state data before unlocking buffer */
		// 获取 元组的xmax和 infomask，此时并不知道 xmax是单纯的事务号还是 MultiXactId
		xwait = HeapTupleHeaderGetRawXmax(tp.t_data);
		infomask = tp.t_data->t_infomask;

		/*
		 * Sleep until concurrent transaction ends -- except when there's a
		 * single locker and it's our own transaction.  Note we don't care
		 * which lock mode the locker has, because we need the strongest one.
		 *
		 * Before sleeping, we need to acquire tuple lock to establish our
		 * priority for the tuple (see heap_lock_tuple).  LockTuple will
		 * release us when we are next-in-line for the tuple.
		 *
		 * If we are forced to "start over" below, we keep the tuple lock;
		 * this arranges that we stay at the head of the line while rechecking
		 * tuple state.
		 */
		 // 如果是 MultiXactId
		if (infomask & HEAP_XMAX_IS_MULTI)
		{
			bool		current_is_member = false;

		// 判断 MultiXactId中保存的锁模式是否与 LockTupleExclusive冲突，冲突则
			if (DoesMultiXactIdConflict((MultiXactId) xwait, infomask,
										LockTupleExclusive, &current_is_member))
			{
				LockBuffer(buffer, BUFFER_LOCK_UNLOCK);

				/*
				 * Acquire the lock, if necessary (but skip it when we're
				 * requesting a lock and already have one; avoids deadlock).
				 */
				 // 如果当前事务不属于MultiXactId成员，则需获取元组级常规锁，反之无需获取，
				 // 其目的是避免死锁
				if (!current_is_member)
					heap_acquire_tuplock(relation, &(tp.t_self), LockTupleExclusive,
										 LockWaitBlock, &have_tuple_lock);

				/* wait for multixact */
				// 等待冲突的事务完成
				MultiXactIdWait((MultiXactId) xwait, MultiXactStatusUpdate, infomask,
								relation, &(tp.t_self), XLTW_Delete,
								NULL);
				LockBuffer(buffer, BUFFER_LOCK_EXCLUSIVE);

				/*
				 * If xwait had just locked the tuple then some other xact
				 * could update this tuple before we get to this point.  Check
				 * for xmax change, and start over if so.
				 */
				 // 如果元组的 infomask被其他事务更新，则需重新进行上述操作
				if (xmax_infomask_changed(tp.t_data->t_infomask, infomask) ||
					!TransactionIdEquals(HeapTupleHeaderGetRawXmax(tp.t_data),
										 xwait))
					goto l1;
			}

			/*
			 * You might think the multixact is necessarily done here, but not
			 * so: it could have surviving members, namely our own xact or
			 * other subxacts of this backend.  It is legal for us to delete
			 * the tuple in either case, however (the latter case is
			 * essentially a situation of upgrading our former shared lock to
			 * exclusive).  We don't bother changing the on-disk hint bits
			 * since we are about to overwrite the xmax altogether.
			 */
		}
		// xwait 是单一事务号，且不是当前事务号
		else if (!TransactionIdIsCurrentTransactionId(xwait))
		{
			/*
			 * Wait for regular transaction to end; but first, acquire tuple
			 * lock.
			 */
			 // 获取元组级常规锁，等待其他事务的更新操作
			LockBuffer(buffer, BUFFER_LOCK_UNLOCK);
			heap_acquire_tuplock(relation, &(tp.t_self), LockTupleExclusive,
								 LockWaitBlock, &have_tuple_lock);
			XactLockTableWait(xwait, relation, &(tp.t_self), XLTW_Delete);
			LockBuffer(buffer, BUFFER_LOCK_EXCLUSIVE);

			/*
			 * xwait is done, but if xwait had just locked the tuple then some
			 * other xact could update this tuple before we get to this point.
			 * Check for xmax change, and start over if so.
			 */
			 // 如果其他事务更新元组，则需回到 l1程序点进行相关操作
			if (xmax_infomask_changed(tp.t_data->t_infomask, infomask) ||
				!TransactionIdEquals(HeapTupleHeaderGetRawXmax(tp.t_data),
									 xwait))
				goto l1;

			/* Otherwise check if it committed or aborted */
			// 更新元组的 HintBit标识位信息
			UpdateXmaxHintBits(tp.t_data, buffer, xwait);
		}

		/*
		 * We may overwrite if previous xmax aborted, or if it committed but
		 * only locked the tuple without updating it.
		 */
		 // 如果 xmax意外终止或者提交但是被他人锁住（未更新）
		if ((tp.t_data->t_infomask & HEAP_XMAX_INVALID) ||
			HEAP_XMAX_IS_LOCKED_ONLY(tp.t_data->t_infomask) ||
			HeapTupleHeaderIsOnlyLocked(tp.t_data))
			result = TM_Ok;
		else if (!ItemPointerEquals(&tp.t_self, &tp.t_data->t_ctid))
			result = TM_Updated;
		else
			result = TM_Deleted;
	}

	if (crosscheck != InvalidSnapshot && result == TM_Ok)
	{
		/* Perform additional check for transaction-snapshot mode RI updates */
		if (!HeapTupleSatisfiesVisibility(&tp, crosscheck, buffer))
			result = TM_Updated;
	}

	if (result != TM_Ok)
	{
		Assert(result == TM_SelfModified ||
			   result == TM_Updated ||
			   result == TM_Deleted ||
			   result == TM_BeingModified);
		Assert(!(tp.t_data->t_infomask & HEAP_XMAX_INVALID));
		Assert(result != TM_Updated ||
			   !ItemPointerEquals(&tp.t_self, &tp.t_data->t_ctid));
		tmfd->ctid = tp.t_data->t_ctid;
		tmfd->xmax = HeapTupleHeaderGetUpdateXid(tp.t_data);
		if (result == TM_SelfModified)
			tmfd->cmax = HeapTupleHeaderGetCmax(tp.t_data);
		else
			tmfd->cmax = InvalidCommandId;
		UnlockReleaseBuffer(buffer);
		if (have_tuple_lock)
			UnlockTupleTuplock(relation, &(tp.t_self), LockTupleExclusive);
		if (vmbuffer != InvalidBuffer)
			ReleaseBuffer(vmbuffer);
		return result;
	}

	/*
	 * We're about to do the actual delete -- check for conflict first, to
	 * avoid possibly having to roll back work we've just done.
	 *
	 * This is safe without a recheck as long as there is no possibility of
	 * another process scanning the page between this check and the delete
	 * being visible to the scan (i.e., an exclusive buffer content lock is
	 * continuously held from this point until the tuple delete is visible).
	 */
	 // 序列化冲突检查
	CheckForSerializableConflictIn(relation, tid, BufferGetBlockNumber(buffer));

	/* replace cid with a combo CID if necessary */
	HeapTupleHeaderAdjustCmax(tp.t_data, &cid, &iscombo);

	/*
	 * Compute replica identity tuple before entering the critical section so
	 * we don't PANIC upon a memory allocation failure.
	 */
	old_key_tuple = ExtractReplicaIdentity(relation, &tp, true, &old_key_copied);

	/*
	 * If this is the first possibly-multixact-able operation in the current
	 * transaction, set my per-backend OldestMemberMXactId setting. We can be
	 * certain that the transaction will never become a member of any older
	 * MultiXactIds than that.  (We have to do this even if we end up just
	 * using our own TransactionId below, since some other backend could
	 * incorporate our XID into a MultiXact immediately afterwards.)
	 */
	MultiXactIdSetOldestMember();
	// 计算新的xmax + infomask + infomask2
	compute_new_xmax_infomask(HeapTupleHeaderGetRawXmax(tp.t_data),
							  tp.t_data->t_infomask, tp.t_data->t_infomask2,
							  xid, LockTupleExclusive, true,
							  &new_xmax, &new_infomask, &new_infomask2);

	START_CRIT_SECTION();
	// 临界区
	/*
	 * If this transaction commits, the tuple will become DEAD sooner or
	 * later.  Set flag that this page is a candidate for pruning once our xid
	 * falls below the OldestXmin horizon.  If the transaction finally aborts,
	 * the subsequent page pruning will be a no-op and the hint will be
	 * cleared.
	 */
	PageSetPrunable(page, xid);

	// 首先清除元组对应数据页 和 vm 页的all visible标识位
	if (PageIsAllVisible(page))
	{
		all_visible_cleared = true;
		PageClearAllVisible(page);
		visibilitymap_clear(relation, BufferGetBlockNumber(buffer),
							vmbuffer, VISIBILITYMAP_VALID_BITS);
	}
	// 更新元组头等相关信息
	/* store transaction information of xact deleting the tuple */
	tp.t_data->t_infomask &= ~(HEAP_XMAX_BITS | HEAP_MOVED);
	tp.t_data->t_infomask2 &= ~HEAP_KEYS_UPDATED;
	tp.t_data->t_infomask |= new_infomask;
	tp.t_data->t_infomask2 |= new_infomask2;
	HeapTupleHeaderClearHotUpdated(tp.t_data);
	HeapTupleHeaderSetXmax(tp.t_data, new_xmax);
	HeapTupleHeaderSetCmax(tp.t_data, cid, iscombo);
	/* Make sure there is no forward chain link in t_ctid */
	tp.t_data->t_ctid = tp.t_self;

	/* Signal that this is actually a move into another partition */
	if (changingPart)
		HeapTupleHeaderSetMovedPartitions(tp.t_data);

	MarkBufferDirty(buffer);

	/*
	 * XLOG stuff
	 *
	 * NB: heap_abort_speculative() uses the same xlog record and replay
	 * routines.
	 */
	 // 写XLOG日志，奔溃恢复
	if (RelationNeedsWAL(relation))
	{
		xl_heap_delete xlrec;
		xl_heap_header xlhdr;
		XLogRecPtr	recptr;

		/*
		 * For logical decode we need combo CIDs to properly decode the
		 * catalog
		 */
		if (RelationIsAccessibleInLogicalDecoding(relation))
			log_heap_new_cid(relation, &tp);

		xlrec.flags = 0;
		if (all_visible_cleared)
			xlrec.flags |= XLH_DELETE_ALL_VISIBLE_CLEARED;
		if (changingPart)
			xlrec.flags |= XLH_DELETE_IS_PARTITION_MOVE;
		xlrec.infobits_set = compute_infobits(tp.t_data->t_infomask,
											  tp.t_data->t_infomask2);
		xlrec.offnum = ItemPointerGetOffsetNumber(&tp.t_self);
		xlrec.xmax = new_xmax;

		if (old_key_tuple != NULL)
		{
			if (relation->rd_rel->relreplident == REPLICA_IDENTITY_FULL)
				xlrec.flags |= XLH_DELETE_CONTAINS_OLD_TUPLE;
			else
				xlrec.flags |= XLH_DELETE_CONTAINS_OLD_KEY;
		}

		XLogBeginInsert();
		XLogRegisterData((char *) &xlrec, SizeOfHeapDelete);

		XLogRegisterBuffer(0, buffer, REGBUF_STANDARD);

		/*
		 * Log replica identity of the deleted tuple if there is one
		 */
		if (old_key_tuple != NULL)
		{
			xlhdr.t_infomask2 = old_key_tuple->t_data->t_infomask2;
			xlhdr.t_infomask = old_key_tuple->t_data->t_infomask;
			xlhdr.t_hoff = old_key_tuple->t_data->t_hoff;

			XLogRegisterData((char *) &xlhdr, SizeOfHeapHeader);
			XLogRegisterData((char *) old_key_tuple->t_data
							 + SizeofHeapTupleHeader,
							 old_key_tuple->t_len
							 - SizeofHeapTupleHeader);
		}

		/* filtering by origin on a row level is much more efficient */
		XLogSetRecordFlags(XLOG_INCLUDE_ORIGIN);

		recptr = XLogInsert(RM_HEAP_ID, XLOG_HEAP_DELETE);

		PageSetLSN(page, recptr);
	}

	END_CRIT_SECTION();
	// 退出临界区 + 释放锁+内存资源
	LockBuffer(buffer, BUFFER_LOCK_UNLOCK);

	if (vmbuffer != InvalidBuffer)
		ReleaseBuffer(vmbuffer);

	/*
	 * If the tuple has toasted out-of-line attributes, we need to delete
	 * those items too.  We have to do this before releasing the buffer
	 * because we need to look at the contents of the tuple, but it's OK to
	 * release the content lock on the buffer first.
	 */
	if (relation->rd_rel->relkind != RELKIND_RELATION &&
		relation->rd_rel->relkind != RELKIND_MATVIEW)
	{
		/* toast table entries should never be recursively toasted */
		Assert(!HeapTupleHasExternal(&tp));
	}
	else if (HeapTupleHasExternal(&tp))
		heap_toast_delete(relation, &tp, false);

	/*
	 * Mark tuple for invalidation from system caches at next command
	 * boundary. We have to do this before releasing the buffer because we
	 * need to look at the contents of the tuple.
	 */
	 // 将删除元组在内存中对应的 cache 标记为无效 ==> 普通表元组不执行，系统表元组会标记
	CacheInvalidateHeapTuple(relation, &tp, NULL);

	/* Now we can release the buffer */
	ReleaseBuffer(buffer);

	/*
	 * Release the lmgr tuple lock, if we had it.
	 */
	if (have_tuple_lock)
		UnlockTupleTuplock(relation, &(tp.t_self), LockTupleExclusive);

	pgstat_count_heap_delete(relation);

	if (old_key_tuple != NULL && old_key_copied)
		heap_freetuple(old_key_tuple);

	return TM_Ok;
}

更新流程

写-写冲突采取的是两阶段锁协议。

整个事务分为两个阶段，前一个阶段为加锁，后一个阶段为解锁。在加锁阶段，事务只能加锁，也可以操作数据，但不能解锁，直到事务释放第一个锁，就进入解锁阶段，此过程中事务只能解锁，也可以操作数据，不能再加锁。两阶段锁协议使得事务具有较高的并发度，因为解锁不必发生在事务结尾。

它的不足是没有解决死锁的问题，因为它在加锁阶段没有顺序要求。如两个事务分别申请了A, B锁，接着又申请对方的锁，此时进入死锁状态。

pg应对死锁：查询执行中的sql、查询等待锁的事务、手动取消和回滚事务、

heap_update
	block = ItemPointerGetBlockNumber(otid);
	LockBuffer(buffer, BUFFER_LOCK_EXCLUSIVE);
	oldtup.t_data = (HeapTupleHeader)PageGetItem(page, lp);
	HeapSatisfiesHOTUpdate(relation, hot_attrs, key_attrs, id_attrs, &satisfies_hot,
        &satisfies_key, &satisfies_id, &oldtup, newtup, page);
	result = HeapTupleSatisfiesUpdate(&oldtup, cid, buffer, allow_update_self);

	CheckForSerializableConflictIn(relation, &oldtup, buffer);
	HeapTupleSetOid(newtup, HeapTupleGetOid(&oldtup));
	heap_page_prepare_for_xid(relation, buffer, xid, false);

参考

https://blog.csdn.net/s_lisheng/article/details/139782641

https://blog.csdn.net/qq_37517281/article/details/104399535

https://blog.csdn.net/qq_52668274/article/details/128575448
